DIPON Epoxyplast 3D B20 JEWELCAST - Part B

Code: 6418/000250 6418/000500 6418/001000 6418/002500 Choose variant

Not rated

DIPON Epoxyplast 3D B20 JEWELCAST - Part B

7,55 € 11,93 € 19,66 € 46,08 € from 7,55 € 6,24 € excl. VAT 9,86 € excl. VAT 16,25 € excl. VAT 38,08 € excl. VAT from 6,24 € excl. VAT – 23,86 € / 1 kg 19,66 € / 1 kg 18,43 € / 1 kg –

(>5 pcs) (>5 pcs) (>5 pcs) (>5 pcs) Choose variant

Delivery to: 24/12/2024 24/12/2024 24/12/2024 24/12/2024 Choose variant Delivery offer
Mass
Chosen variant is not available. Reset selected parameters.

Clear casting epoxy resin for small castings, casting thickness 0.1 - 2 cm (at max 22 °C), cures from 15 °C, hardness 83 SHORE D, VOC 0 g/L, mixing ratio by weight 2:1, can be sanded after 2 - 3 days

Technical Data Sheet

Detailed information

Product detailed description

DIPON EpoxyPlast 3D B20 Jewel Cast

EpoxyPlast 3D B20 Jewel Cast is a highly transparent epoxy resin that stands out with its advanced UV stabilization using UV absorbers and HALS stabilizers. This resin is designed for a wide range of applications, from resin art projects to woodworking and floor coatings. Its high resistance to yellowing and mechanical durability make it an ideal choice for demanding creators.

Thanks to its self-degassing formulation, it ensures smooth surfaces free of bubbles, while its low susceptibility to carbamate formationenhances the quality and durability of the final layer. EpoxyPlast 3D B20 Jewel Cast is part of the unique EpoxyPlast 3D system, combining one resin with three compatible hardeners for maximum flexibility. Recommended layer thicknesses of 1 mm to 20 mm at 20 °C allow precise work on both small and large projects.

The formulation of this resin is eco-friendly – with over 70% biobased components, it contributes to sustainable production. EpoxyPlast 3D B20 Jewel Cast offers the possibility of food contact after complete curing, making it ideal for projects such as kitchen countertops, jewelry, or artistic decorations.

DIPON Epoxyplast 3D B20 JEWELCAST - Složka B tužidlo

Key Features

Crystal-clear transparency: Excellent optical quality for perfect details.
UV protection: Resistance to yellowing with advanced UV absorbers and HALS additives.
Wide applicability: Ideal for Resin Art, woodworking, flooring, and other creative projects.
Perfect surface: Self-degassing properties for smooth, bubble-free surfaces.
Eco-friendly: More than 70% biobased components.
Flexible application: Part of the EpoxyPlast 3D system with three hardeners for different viscosities and working times.

General Characteristics

Stable formulation against crystallization
Comparable to LuminaCast 4 Gem Flow, but slightly slower
Contains UV absorbers and n-HALS light stabilizers
Lower susceptibility to carbamate formation
Highly transparent glass-like curing after hardening
Excellent self-degassing properties
Biobased components included in the epoxy resin
Free from substances listed in CoRAP and sVHC
Modern low-yellowing base amines and additives
0 % VOC (according to EU standards)
Excellent substrate wetting
Very low shrinkage (<0.1 %)
Compatible with materials such as wood, concrete, glass, metal, fiberglass, carbon fibers, natural stone, quartz sand, marble, and granite

Technical Data

Dynamic viscosity of resin A (23 °C): 550 ± 50 mPa·s
Dynamic viscosity of hardener B (23 °C): 800 ± 50 mPa·s
Mixing ratio: 2:1 (resin A + hardener B) by weight
Processing time (23 °C, 200 grams, 10 mm): approximately 55 minutes (23 °C - 40 °C)
tTMax (23 °C, 200 grams, 20 mm): Time to maximum exotherm, approximately 110 minutes
Recommended material temperature (A + B): minimum 20 °C, recommended 23 °C
Recommended ambient temperature: minimum 10 °C, recommended 15–25 °C
Recommended casting height (20 °C): 0.1–2 cm (1–20 mm)
Demoldable (23 °C, 20 mm): approximately 16–24 hours
Next layer applicable after: approximately 8–12 hours at 20 °C (15–20 mm)
Minimum recommended mixing amount (A + B): 120 grams
Sandable: approximately 5–7 days, at 20 mm and 23 °C (RT)
Hardness after 7 days (23 °C): Shore D83
Heat resistance: approximately 71 °C

UV resistant

The unique formulation offers excellent UV resistance. Resistant to yellowing over time.

Small castings up to 2 cm

It enables casting of small castings up to 2 cm thick (at 20°C).

Processing time up to 55 min

The long processing time of up to 55 min provides sufficient time for mixing, pigmentation and debubbling of the mixture. Depending on the amount of material.

Cures at temperatures from 10 °C

It cures at low temperatures as low as 10 °C, which is appreciated by everyone, especially in the winter months, when heating production areas is costly.

Areas of Application

Petri Art and artistic techniques: With EpoxyPlast 3D B20 JewelCast, you can create elegant resin art. Ideal for casting heights from 1 mm to 20 mm (at 20 °C). Higher casting heights are possible at lower ambient temperatures.
Production of glass and carbon laminates: Also suitable for other forms where outstanding clarity is essential.
Flexibility in use: Whether for jewelry making, kitchen countertops, flooring, sealants, or woodworking, LuminaCast 4 Gem Flowalways delivers perfect results.
Food contact: The formulation is free of substances listed in sVHC or CoRAP. After complete chemical curing, the product is suitable for contact with food.

What is EpoxyPlast 3D?

EpoxyPlast 3D was developed in 2019 as a self-venting system that is easy to use and covers a wide range of applications, especially in the artistic field.
Since its launch, it has become a popular choice among users, particularly EpoxyPlast 3D B20 Jewel Cast, which has been used by more than 100,000 users since 2019. Additionally, the well-known thick-film systems, such as EpoxyPlast 3D B50 Deep Pour and EpoxyPlast 3D B100 Ultra Pour – the first systems in Germany capable of casting up to 10 cm in depth – have also proven highly effective.
These epoxy systems have been applied hundreds of thousands of times with outstanding results, demonstrating their reliability and ability to create perfect surfaces for demanding projects.

Typ	Dyn. viskozita 23 °C (mPas)	**Zpracovatelnost: 200g, 23 °C - 40 °C	Max. síla odlitku	Použití	UV odolnost
EpoxyPlast 3D B20 Jewel Cast	800 ± 50	cca 55 min	0,1 mm - 20 mm	Art & Vložení	Excelentní
EpoxyPlast 3D B50 Deep Pour	75 ± 25	cca 180 min 500 gramů, 5cm**	20 mm - 50 mm	Zalévání silných odlitků	Excelentní
EpoxyPlast 3D B100 Ultra Pour	50 ± 25	cca 240 min 500 gramů, 9cm**	30 mm - 100 mm	Zalévání silných odlitků	Excelentní

*Dynamická viskozita se měří při 23°C. Snížení teploty materiálu je doprovázeno neúměrným zvýšením dyn. viskozity. To je eminentně důležité, zejména pokud jde o samoodvzdušňování.
**Doba zpracování je uvedena pro směs 200 gramů v mixovací nádobě (průměr 5 cm). Doba zpracování = teplota materiálu 23°C -> 40°C = zdvojnásobení počáteční viskozity. Čas na maximální exotermickou teplotu (tTmax) je obvykle dvojnásobkem doby zpracování.

EpoxyPlast 3D Složka A - epoxidová pryskyřice pro všechna tvrdila EpoxyPlast 3D - (580 mPa*s ± 50, 23°C)
EpoxyPlast 3D B20 Jewel Cast - Nízká viskozita, zpracovatelnost cca 55 min, pro drobné odlitky.
EpoxyPlast 3D B50 Deep Pour- Nízká viskozita, pro velké tlustovrstvé odlitky, např. pro říční stoly, výrobu lamp, větší odlitky v jednom lití.
EpoxyPlast 3D B100 Ultra Pour - Nízká viskozita, pro velmi velké tlustovrstvé odlitky, např. pro říční stoly, výrobu lamp.

Application and Usage

Check the ambient temperature, as it's the most critical parameter alongside the casting volume. Successful application depends on room temperature and the amount/volume of the resin and hardener mix used. An excessively high room temperature can lead to a very strong exothermic reaction, resulting in yellowing, cracking, and vapor formation in the mixture.
Before use, perform a preliminary test for material compatibility to be painted/poured.
The recommended procedure for the most accurate measurement of all components is by weight, precisely weighing in a 100:50 or 2:1 weight parts ratio based on component (A). Even a slight deviation results in extended or non-occurring hardening. Adding too much hardener increases the material's elasticity and decreases its SHORE D hardness. Excess of component A results in a permanently sticky film, non-reversible due to polyaddition. The maximum deviation in the tolerance range is 0.1%.
Adhere to the recommended mixing time of three to four minutes, then pour into a clean container and mix again for three to four minutes to achieve a maximally homogeneous mixture.
Use the mixing container only once. Follow the recommended maximum mixing speed for both components, which is 300 rpm, preventing or minimizing the formation of air pockets during mixing. Manual mixing is recommended for smaller quantities up to approx. 1 kg. Due to its extended work time, it degasses excellently. We recommend using Allway Tools Helix for mixing.
To prevent resin seepage due to the prolonged curing time, ensure complete sealing of the mold. Suitable for this is the DIPON polypropylene tape, which can be easily separated from the mold after hardening. Optionally, a release wax can be used.

Cleaning

For cleaning used applicators, use acetone or universal thinner. Once the epoxy resin hardens, it can only be removed by sanding. Cleaning immediately after use is recommended.

Important Note:

Mixing transport containers (bottles/cans) A (resin) and B (hardener) will result in incomplete hardening and the corresponding incorrect result. Always weigh both components precisely.
The higher the room temperature and the larger the mixed quantity, the faster the exothermic reaction.
