Product detailed description
DIPON LuminaCast 10 Cell Flow
DIPON LuminaCast 10 Cell Flow is a clear medium viscosity epoxy resin. Thanks to its balanced viscosity, which is almost twice that of LuminaCast 5 Radiant Flow, this highly transparent system sets new standards in terms of quality and variety of applications. With a viscosity of 2500 mPa*s, it offers a slow flow that enables techniques that would not be possible with less viscous resins. LuminaCast 10 Cell Flow ranks at the top with its third highest viscosity within the LuminaCast system.
With a refractive index > 1.59, this product is among the most transparent epoxy resins on the market.
![DIPON LuminaCast 10 Cell Flow 0,75 kg - Středně viskózní epoxidová pryskyřice, tloušťka 20 mm](https://image.pobo.cz/images/b5aehi2phuw6/p58pbah9pxw6a9cfbon7-md.jpeg)
Key features of LuminaCast 10 Cell Flow
- Mixing ratio 2:1 by weight.
- Casting height up to 20 mm and processing time up to 50 minutes depending on quantity and ambient temperature.
- Unmolding possible after 16 - 24 hours (23 °C).
- Medium viscous 2500 mPa*s.
- Cell and Wave Effects: Ideal for epoxy ART and for marine (sea waves) and cell effects.
- It holds the shape and prevents pigments from floating away.
- The next layer can be poured after approx. 12 - 16 hours (10 mm / 20 °C).
- It creates an incomparably smooth and shiny surface.
- The advanced formulation minimizes carbamate formation and ensures a flawless, blemish-free finish.
![DIPON LuminaCast 10 Cell Flow 0,75 kg - Středně viskózní epoxidová pryskyřice, tloušťka 20 mm](https://image.pobo.cz/images/b5aehi2phuw6/etvba1mq7027f75ww47h-md.webp)
Maximum UV protection
![DIPON LuminaCast 10 Cell Flow 0,75 kg - Středně viskózní epoxidová pryskyřice, tloušťka 20 mm](https://image.pobo.cz/images/b5aehi2phuw6/kz578cfw6hh17fad4sgw-md.png)
Casting height up to 20 mm
Up to 20 mm (20°C) in a single pour, depending on the amount of material and ambient temperature.![DIPON LuminaCast 10 Cell Flow 0,75 kg - Středně viskózní epoxidová pryskyřice, tloušťka 20 mm](https://image.pobo.cz/images/b5aehi2phuw6/v60xnxejtbsyt9i2fp9a-md.webp)
Workability up to 50 mins
Extended workability provides ample time for mixing, pigmenting, and degassing the mixture (at 23°C, 200g, 20 mm).![DIPON LuminaCast 10 Cell Flow 0,75 kg - Středně viskózní epoxidová pryskyřice, tloušťka 20 mm](https://image.pobo.cz/images/b5aehi2phuw6/0weudsuiszjczsdzqs97-md.webp)
Mixing ratio 2:1 by weight
Very easy mixing and calculation of the correct amount of individual components.Application and use
- Elegance in Petri Art: With LuminaCast 10 Cell Flow, you create breathtaking resin artworks that captivate every viewer.
- Masterful in wave & cell technique: Thanks to its optimal flow properties, this product is ideal for impressive marine images and all kinds of cell effects.
- Doming on a new level: The outstanding surface tension enables impressive doming effects.
- Versatility for all projects: Whether it's jewellery, kitchen worktops, flooring, sealants or wood crafts, LuminaCast 10 Cell Flow always delivers excellent results.
- Safety and food contact: Our carefully formulated formula contains no sVHC or CoRAP substances. Once fully cured, LuminaCast is safe to come into contact with food.
![DIPON LuminaCast 10 Cell Flow 0,75 kg - Středně viskózní epoxidová pryskyřice, tloušťka 20 mm](https://image.pobo.cz/images/b5aehi2phuw6/fmlot48lgviaafmq615w-md.jpeg)
General Characteristics
- Crystallization stable
- Bio-based ingredients in the epoxy resin
- Free from CoRAP and sVHC substances
- State-of-the-art base amines and additives with particularly low yellowing tendencies
- Mixing ratio: 2:1 by weight (A+B)
- Pot life (23°C), 200 grams, 2 cm: approx. 50 min. (23°C- > 40°C)
- Recommended material temperature (A+B): 20°- 24°C
- Recommended ambient temperature: 20°C - 25°C
- Dyn. Viscosity (mPa*s) 23°C: A 730 ± 50
- Dyn. Viscosity (mPa*s) 23°C: B 2500 ± 50
- Diamond Clear transparency
- Layer thickness (20°C): 1 - 20 mm
- 0% VOC content
- Excellent substrate wetting capability
- Very low shrinkage (<0.1%)
- Compatible with, e.g., wood, concrete, glass, metal, glass and carbon fiber fabrics, natural stone, quartz sand, marble, granite
Key Application Data
- Pot life at 23°C (200 grams, 20 mm): approx. 50 min.
- Time to max exothermy (tTmax) (23°C, 200 grams, 20 mm): approx. 100 min.
- Mixing duration: 3-4 min. + transfer and another 3-4 min for a uniform mixture
- Mixing ratio: 2:1 by weight (A+B)
- Recommended casting height (20°C): 0.1 cm - 2.0 cm (1 - 20 mm)
- Demoldable after (23°C): approx. 16 - 24 hrs.
- Next layer pourable after: approx. 12 - 16 hrs. at 20°C, 10 mm
- Minimum recommended mixing amount: 120 grams A+B
How to use
Application and Usage
- Check the ambient temperature, as it's the most critical parameter alongside the casting volume. Successful application depends on room temperature and the amount/volume of the resin and hardener mix used. An excessively high room temperature can lead to a very strong exothermic reaction, resulting in yellowing, cracking, and vapor formation in the mixture.
- Before use, perform a preliminary test for material compatibility to be painted/poured.
- The recommended procedure for the most accurate measurement of all components is by weight, precisely weighing in a 100:50 or 2:1 weight parts ratio based on component (A). Even a slight deviation results in extended or non-occurring hardening. Adding too much hardener increases the material's elasticity and decreases its SHORE D hardness. Excess of component A results in a permanently sticky film, non-reversible due to polyaddition. The maximum deviation in the tolerance range is 0.1%.
- Adhere to the recommended mixing time of three to four minutes, then pour into a clean container and mix again for three to four minutes to achieve a maximally homogeneous mixture.
- Use the mixing container only once. Follow the recommended maximum mixing speed for both components, which is 300 rpm, preventing or minimizing the formation of air pockets during mixing. Manual mixing is recommended for smaller quantities up to approx. 1 kg. Due to its extended work time, it degasses excellently. We recommend using Allway Tools Helix for mixing.
- To prevent resin seepage due to the prolonged curing time, ensure complete sealing of the mold. Suitable for this is the DIPON polypropylene tape, which can be easily separated from the mold after hardening. Optionally, a release wax can be used.
Cleaning
- For cleaning used applicators, use acetone or universal thinner. Once the epoxy resin hardens, it can only be removed by sanding. Cleaning immediately after use is recommended.
Important Note:
- Mixing transport containers (bottles/cans) A (resin) and B (hardener) will result in incomplete hardening and the corresponding incorrect result. Always weigh both components precisely.
- The higher the room temperature and the larger the mixed quantity, the faster the exothermic reaction.
Recommended minimum mixed amount 90 grams
*If the amount of mixture falls below the minimum of 90 grams, the curing time may be extended. It is also possible to create a mass that is not completely homogeneous and the exothermic reaction is too low to completely harden the workpiece. The recommended minimum amount of mixture is 90 grams (A 60 grams + B 30 grams), the recommended amount is 120 grams (80 grams A + 40 grams B).![DIPON LuminaCast 10 Cell Flow 0,75 kg - Středně viskózní epoxidová pryskyřice, tloušťka 20 mm](https://image.pobo.cz/images/b5aehi2phuw6/mu5nqyx620h8hexpb1m5-md.jpeg)
Food-safe?
The formula contains no substances of SVHC or CoRAP. After complete chemical curing, approximately 14 days at 25°C, the product is suitable for food contact.What is LuminaCast?
- LuminaCast epoxy resin was developed with the aim of creating an unrivaled clear, UV-stabilized, and self-degassing system that's easy to use and covers the widest possible range of applications, particularly in the arts and crafts sector.
- Special attention was given to achieving the highest possible carbamate resistance in all formulations by using the latest raw materials and adding hydrophobic additives. Additionally, besides the most up-to-date UV absorbers and light stabilizers, this system employs only slightly yellowing base amines in the hardener and especially UV-resistant additives. LuminaCast is designed for every application in the decorative sector, be it basic coatings, trays, furniture, or large volume casting.
- With one resin and ten hardeners, you have maximum flexibility and can unleash your creative side!
![DIPON LuminaCast 10 Cell Flow 0,75 kg - Středně viskózní epoxidová pryskyřice, tloušťka 20 mm](https://image.pobo.cz/images/b5aehi2phuw6/b1bjhczg3ybs14acofph-md.jpeg)
LuminaCast (A Component: 730 ± 50 mPa*s, 23°C) consists of ten hardeners and one epoxy
Type | *Dyn. Viscosity 23 °C (mPa*s) | **Proseccing time: 200g, 23 °C - 40 °C | Rec. Max. layer thickness | Purpose of use | UV protection |
---|---|---|---|---|---|
LuminaCast 1 Fast Set Primer | 120 ± 50 | cca 15 min | 0,1 mm - 7 mm | Pre-treatment & priming | Excellent |
LuminaCast 2 Coaster Cast | 290 ± 50 | cca 40 min | 0,1 mm - 15 mm | Highly transparent embeddings | Excellent |
LuminaCast 3 Crystal Flow | 140 ± 50 | cca 35 min | 0,1 mm - 10 mm | Laminations & Art | Excellent |
LuminaCast 4 Gem Flow | 890 ± 50 | cca 55 min | 0,1 mm - 20 mm | Art & Embeddings | Excellent |
LuminaCast 5 Radiant Flow | 1330 ± 50 | cca 60 min | 0,1 mm - 20 mm | Art & Embeddings | Excellent |
LuminaCast 6 Art Flow | 4100 ± 50 | cca 45 min | 0,1 mm - 20 mm | Art & Embeddings | Excellent |
LuminaCast 7 Design Flow | 5500 ± 50 | cca 50 min | 0,1 mm - 20 mm | Art & Embeddings | Excellent |
LuminaCast 8 Table Flow | 70 ± 50 | cca 180 min **500 grams, 9cm | 20 mm - 50 mm | Thick film potting | Excellent |
LuminaCast 9 Ocean Flow | 50 ± 50 | cca 240 min **500 grams, 9cm | 30 mm - 100 mm | Thick film potting | Excellent |
LuminaCast 10 Cell Flow | 2500 ± 50 | cca 50 min | 0,1 mm - 20 mm | Art & Embeddings | Excellent |
*Dynamic viscosity is measured at 23°C. A reduction in the material temperature is accompanied by a disproportionate increase in dyn. Viscosity. This is eminently important, especially when it comes to self-venting. Example. Viscosity Material temperature 23°C. 730 mPa*s, at 10°C Material temperature: approx. 10,000 mPa*s.
**The processing time is given for a mixture of 200 grams in a mixing cup (diameter 5 cm). Processing time = material temperature 23°C -> 40°C = doubling of the initial viscosity. The time to the max. exothermic temperature (tTMax) is usually twice the time of the prosecuting time.
- LuminaCast 1 Fast Set Primer - Low viscosity, pot life, approx. 15 min., can be poured over after 60 - 120 min., ideal as primer / sealer for porous substrates such as wood
- LuminaCast 2 Coaster Cast - Low viscosity, pot life approx. 40 min. ideal for decorative highly transparent embeddings and molds
- LuminaCast 3 Crystal Flow - Especially low viscosity, pot life approx. 35 min. ideal for decorative highly transparent embeddings and molds
- LuminaCast 4 Gem Flow Flow - Low viscosity, pot life approx. 55 min. e.g. for resin art with a higher viscosity, comparable to B20 JewelCast only more viscous
- LuminaCast 5 Radiant Flow - Medium viscosity, pot life approx. 60 min. a.o. like LuminaCast 4 GemFlow, somewhat slower and slower flow properties due to higher viscosity
- LuminaCast 6 Art Flow - High viscosity, pot life approx. 45 min. for painting techniques, resin art, worktops, sealers, similar to HoneyResin
- LuminaCast 7 Design Flow - High viscosity, pot life approx. 50 min. Special flow properties due to actuator, similar to LuminaCast 6 ArtFlow, perceived thinner
- LuminaCast 8 Table Flow - Low viscosity, pot life approx. 180 min. for large thick film castings e.g. for river tables, lamp production, larger castings in one casting
- LuminaCast 9 Ocean Flow - Low viscosity, pot life approx. 240 min. for very large thick film castings e.g. for river tables, lamp production
- LuminaCast 10 Cell Flow - Medium viscosity, pot life approx. 50 min. for cell effects, Petri Art, flower patterns, Resin Art, table tops, sealers etc.
Additional parameters
Category: | Epoxy Resins |
---|---|
Weight: | 0.88 kg |
Casting Size: | Small Casting |
Color: | Clear, Highly transparent |
? Epoxy System Type: | LuminaCast 10 |
? Viscosity: | Medium |
? Hardness: | 72 ShD |
Kontakt s potravinami: | Yes |
Max thicknesses: | 2 cm |
Package weight: | 0,75 Kg |
? Processing time: | Middle time |
Refractive index: | > 1,59 |
? Temperature resistance: | 70 °C |
Type of use: | Jewelry production, Jewelry using silicone molds, Casting, Art, Geode art, Petri Art, Ocean wave, Ocean Art, Floors, Sealing of Floors, 3D Floors, Final treatment 3D Floors, Art Image, Artistic cup design, TopCoat finish, Mirror-glossy surfaces, Epoxy Table TopCoat, Worktops |
? UV Resistance: | Yes, Maximal |
