DIPON LuminaCast 8 Table Flow 7,5 kg - Low Viscosity Epoxy Resin, Thickness 5 cm
Code: 7257/007500Related products
Crystal clear penetrating / sealing epoxy resin with maximum UV protection, casting thickness up to 7 mm, processing time approx. 15 min, low viscosity (liquid), safe for...
Crystal clear penetrating / sealing epoxy resin with maximum UV protection, casting thickness up to 7 mm, processing time approx. 15 min, low viscosity (liquid), safe for...
Single-component solution designed for effective and quick removal and cleaning of surfaces from grease, oil, wax, dust, and similar contaminant.
Construction polypropylene tape for the production of epoxy molds. Length 55m, width 60mm
High quality polypropylene tape for excellent separation of casting from mold, 48 mm x 66 m
Product detailed description
DIPON LuminaCast 8 Table Flow
LuminaCast 8 Table Flow is a low viscosity clear epoxy resin that boasts high transparency. This casting epoxy resin has been specially developed for casting medium-sized projects such as conference and side tables, including epoxy river tables, designer furniture, lamps and more.
Are you looking for a quality epoxy resin with a long shelf life? LuminaCast 9 Table Flow will offer you the possibility of casting up to 5 cm thick layers in one step. With a refractive index > 1.59, this product is among the most transparent epoxy resins on the market.
Key features of LuminaCast 8 Table Flow
- Mixing ratio 2:1 by weight (or 100:40 by weight for higher strength)
- Casting height up to 5 cm and a long processing time of up to 180 minutes, depending on the quantity and ambient temperature.
- Optimized for furniture manufacturers such as casting tables, making lamps or jewelry, where a larger casting height is required.
- Demoulding possible after 72 - 96 hours (23 °C).
- Sandable after min. 8 days (20 °C).
- It creates an incomparably smooth and shiny surface.
- The advanced formulation minimizes carbamate formation and ensures a flawless, blemish-free finish.
Maximum UV protection
Casting height up to 5 cm
Up to 5 cm (20°C) in a single pour, depending on the amount of material and ambient temperature.Workability up to 3 hours
Extended workability provides ample time for mixing, pigmenting, and degassing the mixture (at 23°C, 500g, 50mm).Mixing ratio 2:1 by weight
For higher strength, it can be mixed in a ratio of 100:40 by weight.High-quality epoxy resin for River Tables
LuminaCast 8 Table Flow is specially designed for making impressive River Tables and for use in large silicone molds. It allows a watering height of up to 50 mm at 20 °C. Note that higher casting heights are possible depending on room temperature and amount of material provided it is below 20°C.General Characteristics
- Crystallization stable
- Bio-based ingredients in the epoxy resin
- Free from CoRAP and sVHC substances
- State-of-the-art base amines and additives with particularly low yellowing tendencies
- Mixing ratio: 2:1 by weight or 100:40 by weight for higher strength
- Pot life (23°C), 500 grams, 5 cm: approx. 180 min. (23°C- > 40°C)
- Recommended material temperature (A+B): 20°- 24°C
- Recommended ambient temperature: 15°C - 20°C
- Dyn. Viscosity (mPa*s) 23°C: A 730 ± 50
- Dyn. Viscosity (mPa*s) 23°C: B 70 ± 25
- Diamond Clear transparency
- Layer thickness (23°C): 20 - 50 mm
- 0% VOC content
- Excellent substrate wetting capability
- Very low shrinkage (<0.1%)
- Compatible with, e.g., wood, concrete, glass, metal, glass and carbon fiber fabrics, natural stone, quartz sand, marble, granite
Key Application Data
- Pot life at 23°C (500 grams, 90 mm): approx. 180 min.
- Time to max exothermy (tTmax) (23°C, 500 grams, 90 mm): approx. 360 min.
- Mixing duration: 3-4 min. + transfer and another 3-4 min for a uniform mixture
- Mixing ratio: 2:1 by weight or 100:40 by weight for higher strength
- Recommended casting height (20°C): 2.0 cm - 5.0 cm (20 - 50 mm)
- Demoldable after (23°C): approx. 72 - 96 hrs.
- Next layer pourable after: approx. 28 - 36 hrs. at 20°C, 50 mm
- Minimum recommended mixing amount: 120 grams A+B
- Sandable after: min. 8 days, 50 mm, 20°C
How to use
Application and Usage
- Check the ambient temperature, as it's the most critical parameter alongside the casting volume. Successful application depends on room temperature and the amount/volume of the resin and hardener mix used. An excessively high room temperature can lead to a very strong exothermic reaction, resulting in yellowing, cracking, and vapor formation in the mixture.
- Before use, perform a preliminary test for material compatibility to be painted/poured.
- The recommended procedure for the most accurate measurement of all components is by weight, precisely weighing in a 100:50 or 2:1 weight parts ratio based on component (A). Even a slight deviation results in extended or non-occurring hardening. Adding too much hardener increases the material's elasticity and decreases its SHORE D hardness. Excess of component A results in a permanently sticky film, non-reversible due to polyaddition. The maximum deviation in the tolerance range is 0.1%.
- Adhere to the recommended mixing time of three to four minutes, then pour into a clean container and mix again for three to four minutes to achieve a maximally homogeneous mixture.
- Use the mixing container only once. Follow the recommended maximum mixing speed for both components, which is 300 rpm, preventing or minimizing the formation of air pockets during mixing. Manual mixing is recommended for smaller quantities up to approx. 1 kg. Due to its extended work time, it degasses excellently. We recommend using Allway Tools Helix for mixing.
- To prevent resin seepage due to the prolonged curing time, ensure complete sealing of the mold. Suitable for this is the DIPON polypropylene tape, which can be easily separated from the mold after hardening. Optionally, a release wax can be used.
Cleaning
- For cleaning used applicators, use acetone or universal thinner. Once the epoxy resin hardens, it can only be removed by sanding. Cleaning immediately after use is recommended.
Important Note:
- Mixing transport containers (bottles/cans) A (resin) and B (hardener) will result in incomplete hardening and the corresponding incorrect result. Always weigh both components precisely.
- The higher the room temperature and the larger the mixed quantity, the faster the exothermic reaction.
Recommended minimum mixed amount 90 grams
*If the amount of mixture falls below the minimum of 90 grams, the curing time may be extended. It is also possible to create a mass that is not completely homogeneous and the exothermic reaction is too low to completely harden the workpiece. The recommended minimum amount of mixture is 90 grams (A 60 grams + B 30 grams), the recommended amount is 120 grams (80 grams A + 40 grams B).Food-safe?
The formula contains no substances of SVHC or CoRAP. After complete chemical curing, approximately 14 days at 25°C, the product is suitable for food contact.What is LuminaCast?
- LuminaCast epoxy resin was developed with the aim of creating an unrivaled clear, UV-stabilized, and self-degassing system that's easy to use and covers the widest possible range of applications, particularly in the arts and crafts sector.
- Special attention was given to achieving the highest possible carbamate resistance in all formulations by using the latest raw materials and adding hydrophobic additives. Additionally, besides the most up-to-date UV absorbers and light stabilizers, this system employs only slightly yellowing base amines in the hardener and especially UV-resistant additives. LuminaCast is designed for every application in the decorative sector, be it basic coatings, trays, furniture, or large volume casting.
- With one resin and ten hardeners, you have maximum flexibility and can unleash your creative side!
LuminaCast (A Component: 730 ± 50 mPa*s, 23°C) consists of ten hardeners and one epoxy
Type | *Dyn. Viscosity 23 °C (mPa*s) | **Proseccing time: 200g, 23 °C - 40 °C | Rec. Max. layer thickness | Purpose of use | UV protection |
---|---|---|---|---|---|
LuminaCast 1 Fast Set Primer | 120 ± 50 | cca 15 min | 0,1 mm - 7 mm | Pre-treatment & priming | Excellent |
LuminaCast 2 Coaster Cast | 290 ± 50 | cca 40 min | 0,1 mm - 15 mm | Highly transparent embeddings | Excellent |
LuminaCast 3 Crystal Flow | 140 ± 50 | cca 35 min | 0,1 mm - 10 mm | Laminations & Art | Excellent |
LuminaCast 4 Gem Flow | 890 ± 50 | cca 55 min | 0,1 mm - 20 mm | Art & Embeddings | Excellent |
LuminaCast 5 Radiant Flow | 1330 ± 50 | cca 60 min | 0,1 mm - 20 mm | Art & Embeddings | Excellent |
LuminaCast 6 Art Flow | 4100 ± 50 | cca 45 min | 0,1 mm - 20 mm | Art & Embeddings | Excellent |
LuminaCast 7 Design Flow | 5500 ± 50 | cca 50 min | 0,1 mm - 20 mm | Art & Embeddings | Excellent |
LuminaCast 8 Table Flow | 70 ± 50 | cca 180 min **500 grams, 9cm | 20 mm - 50 mm | Thick film potting | Excellent |
LuminaCast 9 Ocean Flow | 50 ± 50 | cca 240 min **500 grams, 9cm | 30 mm - 100 mm | Thick film potting | Excellent |
LuminaCast 10 Cell Flow | 2500 ± 50 | cca 50 min | 0,1 mm - 20 mm | Art & Embeddings | Excellent |
*Dynamic viscosity is measured at 23°C. A reduction in the material temperature is accompanied by a disproportionate increase in dyn. Viscosity. This is eminently important, especially when it comes to self-venting. Example. Viscosity Material temperature 23°C. 730 mPa*s, at 10°C Material temperature: approx. 10,000 mPa*s.
**The processing time is given for a mixture of 200 grams in a mixing cup (diameter 5 cm). Processing time = material temperature 23°C -> 40°C = doubling of the initial viscosity. The time to the max. exothermic temperature (tTMax) is usually twice the time of the prosecuting time.
- LuminaCast 1 Fast Set Primer - Low viscosity, pot life, approx. 15 min., can be poured over after 60 - 120 min., ideal as primer / sealer for porous substrates such as wood
- LuminaCast 2 Coaster Cast - Low viscosity, pot life approx. 40 min. ideal for decorative highly transparent embeddings and molds
- LuminaCast 3 Crystal Flow - Especially low viscosity, pot life approx. 35 min. ideal for decorative highly transparent embeddings and molds
- LuminaCast 4 Gem Flow Flow - Low viscosity, pot life approx. 55 min. e.g. for resin art with a higher viscosity, comparable to B20 JewelCast only more viscous
- LuminaCast 5 Radiant Flow - Medium viscosity, pot life approx. 60 min. a.o. like LuminaCast 4 GemFlow, somewhat slower and slower flow properties due to higher viscosity
- LuminaCast 6 Art Flow - High viscosity, pot life approx. 45 min. for painting techniques, resin art, worktops, sealers, similar to HoneyResin
- LuminaCast 7 Design Flow - High viscosity, pot life approx. 50 min. Special flow properties due to actuator, similar to LuminaCast 6 ArtFlow, perceived thinner
- LuminaCast 8 Table Flow - Low viscosity, pot life approx. 180 min. for large thick film castings e.g. for river tables, lamp production, larger castings in one casting
- LuminaCast 9 Ocean Flow - Low viscosity, pot life approx. 240 min. for very large thick film castings e.g. for river tables, lamp production
- LuminaCast 10 Cell Flow - Medium viscosity, pot life approx. 50 min. for cell effects, Petri Art, flower patterns, Resin Art, table tops, sealers etc.
Additional parameters
Category: | Epoxy Resins |
---|---|
Weight: | 7.89 kg |
? Processing time: | Long Time |
? Epoxy System Type: | LuminaCast 8 |
Color: | Clear, Highly transparent |
Package weight: | 7,5 Kg |
Refractive index: | > 1,59 |
Kontakt s potravinami: | Yes |
Max thicknesses: | 5 cm |
? UV Resistance: | Yes, Maximal |
? Temperature resistance: | 70 °C |
? Hardness: | 72 ShD |
Type of use: | River Tables, Conference and side tables - middle, Serving / charcuterie boards, Lambs, Casting, Casting of Flowers |
Casting Size: | Medium Casting |
? Viscosity: | Low - Thin |
Clear casting epoxy resin with maximum UV protection, casting thickness up to 10cm, low viscosity, workability up to 240 minutes, food-safe, mixing ratio 2:1 by weight, can be...
Clear casting epoxy resin with maximum UV protection, casting thickness up to 10cm, low viscosity, workability up to 240 minutes, food-safe, mixing ratio 2:1 by weight, can be...
Clear casting epoxy resin for large castings, casting thickness up to 10 cm (at max 20 °C), cures from 10 °C, hardness 77 SHORE D, VOC 0 g/L, mixing ratio by weight 2:1, full...
Clear casting epoxy resin with maximum UV protection, casting thickness up to 10cm, low viscosity, workability up to 240 minutes, food-safe, mixing ratio 2:1 by weight, can be...
Clear casting epoxy resin for medium casts, casting thickness 0.1 - 5 cm (at max 20 °C), cures from 15 °C, hardness 81 SHORE D, VOC 0 g/L, mixing ratio by weight 2:1, can be...
Clear high viscosity (thick) epoxy resin with maximum UV protection, specially designed to meet the demanding needs of professional artists and designers. Casting thickness 1 -...
Clear casting epoxy resin for small castings, casting thickness 0.1 - 2 cm (at max 22 °C), cures from 15 °C, hardness 83 SHORE D, VOC 0 g/L, mixing ratio by weight 2:1, can be...
Clear casting epoxy resin for small castings, casting thickness 0.1 - 2 cm (at max 22 °C), cures from 15 °C, hardness 83 SHORE D, VOC 0 g/L, mixing ratio by weight 2:1, can be...
Clear casting epoxy resin with maximum UV protection, casting thickness 1 - 20 mm, workability about 50 min, medium viscosity, mixing ratio 2:1 by weight.
Clear casting epoxy resin with maximum UV protection, casting thickness 1 - 20 mm, workability about 50 min, medium viscosity, mixing ratio 2:1 by weight.
Clear casting epoxy resin for large castings, casting thickness up to 10 cm (at max 20 °C), cures from 10 °C, hardness 77 SHORE D, VOC 0 g/L, mixing ratio by weight 2:1, full...
